Copper And Aluminium Wire Winder Automatic Coil Winding Machine 200rpm

1 set
MOQ
negotiable
Price
Copper And Aluminium Wire Winder Automatic Coil Winding Machine 200rpm
Features Gallery Product Description Request A Quote
Features
Specifications
Machine Name: Motor Coil Winding Machine
Applicaiton: Windign Motor Coil
Motor Power: 2.2kw
Speed: 0 ~ 200rpm
Counter: 0 ~ 9999.9
Flange Diameter: 350mm
Color: As Requested
Warranty: 12 Months
Highlight:

automatic coil winding machine 200rpm

,

Copper Aluminium wire winding machine

,

1.5kw automatic coil winding machine
Basic Infomation
Place of Origin: China
Brand Name: STT
Model Number: MW350
Payment & Shipping Terms
Packaging Details: seaworthy packing
Delivery Time: 20 days
Payment Terms: T/T, L/C
Supply Ability: 100 sets per year
Product Description

Copper and Aluminium Wire Winder Cheap Motor Coil Winding Machine





Description of motor coil winding machine MW350



Motor Coil Winding Machine MW350 is a special winding machine for winding motor coils and other similar products. The motor coil winding machine is provided with main steel frame, flange, foot pedal, counter,control board, winding motor, gear box, electrical cabinet,etc.





Quick details of motor coil winding machine MW350

  • Winding copper or aluminium wire
  • Rotating speed 200rpm
  • Flange diameter 350mm
  • Winding power 2.2kw
  • One year warranty



Main parameters of motor coil winding machine MW350



Typical standard specifications of motor coil winding machine MW350 are shown below, however, the motor coil winding machine can also be manufactured as requested.

Machine Height: 1400mm
Flange Diameter: 350mm
Winding Speed: 0-200rpm
Counter: 0-9999.9
Max. Capacity: 500KG
Main motor Power: 2.2KW
Colour: As requested
Machine Dimension(L*W*H): 900x700x1400mm



Copper And Aluminium Wire Winder Automatic Coil Winding Machine 200rpm 0

Fig 1: Motor coil winding machine MW350's full view



Copper And Aluminium Wire Winder Automatic Coil Winding Machine 200rpm 1

Fig 2: Motor coil winding machine MW350's control board



Copper And Aluminium Wire Winder Automatic Coil Winding Machine 200rpm 2Copper And Aluminium Wire Winder Automatic Coil Winding Machine 200rpm 3Copper And Aluminium Wire Winder Automatic Coil Winding Machine 200rpm 4Copper And Aluminium Wire Winder Automatic Coil Winding Machine 200rpm 5Copper And Aluminium Wire Winder Automatic Coil Winding Machine 200rpm 6Copper And Aluminium Wire Winder Automatic Coil Winding Machine 200rpm 7Copper And Aluminium Wire Winder Automatic Coil Winding Machine 200rpm 8Copper And Aluminium Wire Winder Automatic Coil Winding Machine 200rpm 9
