Semi Automatic Electric Motor Coil Winding Machine Copper Or Aluminium Wire Winder

Semi Automatic Copper Or Aluminium Wire Electric Motor Coil Winding Machine

Quick Details of motor coil winding machine MW350

• Winding copper or aluminium wire
• Winding speed 200rpm
• Flange diameter 350mm
• Winding power 1.5kw
• One year warranty

Description of motor coil winding machine MW350

Semi Automatic Copper Or Aluminium Wire Coil Winding Machine For Electric Motor MW350 is a special winding machine for winding motor coil and other similar products. This motor coil winding machine is provided with:

• Main steel frame, steel welded frame is very strong
• Flange, to fix the mould for motor coil
• Foot pedal, can be used to switch the rotating direction
• Counter, counting and reverse counting the numbers of turns
• Control board, can preset some parameters through it
• Winding motor, 2.2kw motor provides big torque
• Gear box, several gears to transmit the torque
• Electrical cabinet, in the cabinet, there are some electric component

Main features of motor coil winding machine MW350

• Slow starting, at the beginning of the rotating, the winding speed is very slow
• Smooth running, during the machine running, it is very stable
• Easy operating, operating this winding machine is very easy and simple
• Automatic counting

Main Parameters

Typical standard specifications of MW350 are shown below, however the motor coil winding machine can also be manufactured as requested.

Fig 1: Motor coil winding machine MW350's full view

Fig 2: Motor coil winding machine MW350's control board
