Semi Automatic Copper Wire Motor Winding Coil Machine 400rpm Rotating

Semi Automatic Copper Wire Máquina de bobinado Motor Coil Winding Machine

Description of motor coil winding machine MW150

Semi automatic copper wire Máquina de bobinado motor coil winding machine MW150 can be used to wind motor coil and other similar products. The motor coil winding machine is provided with winding motor, counter, foot pedal and so on. With 2.2kw motor, the motor coil winding machine can provide enough torque to wind the coil. The mold can be mounted on the flange with diameter 150mm. It is very easy to operate the winding machine.

Quick details of motor coil winding machine MW150

• Slow starting
• Smooth running
• Strong pulling force
• High speed
• Simply structure
• Easy operating

Main parameters of coil winding machine of MW150

Typical standard specifications of coil winding machine MW150 are shown below, however, these can be modified as requested.

Fig 1: Motor coil winding machine MW150's full view

Fig 2: Motor coil winding machine MW150's control board
