Semi Automatic Electric Motor Coil Winding Machine 80rpm

Electric Motor Winding Winder Semi Automatic Motor Coil Winding Machine

Description of motor coil winding machine MW1200

Motor coil winding machine MW1200 is a special winding equipment to wind motor coil or other similar products. This kind of motor coil winding machine is automatic winding machine. The winding machine is provided with a counter, foot pedal and etc. One adjustable mold with maximum length 1200mm is provided for the machine. The mold is suitable for winding different sizes of coils and its adjustable range is from 150mm to 1200mm. The foot pedal of the motor coil winding machine is for starting and stopping the machine and it can be also for switching the rotating directions, forward or reverse. The motor coil winding machine features easy operation and so on.

Quick details of motor coil winding machine MW1200

• Motor power 4kw
• Machine body height 1400mm
• Winding speed 0 ~ 80rpm
• Smooth running
• Adjustable blocks
• Simply structure

Main parameters of motor coil winding machine MW1200

Typical standard specifications of motor coil winding machine MW1200 are shown below, however, the motor coil winding machine can also be manufactured as requested.

Fig 1: Motor coil winding machine MW1200's full view

Fig 2: Motor coil winding machine MW1200's control board
