Semi Automatic Electric Motor Coil Winding Machine Stepless Winding Speed

Semi Automatic Electric Motor Coil Winding Machine Stepless Winding Speed

Description of motor coil winding machine MW500

Electric motor coil winding machine MW500 is a special winding wire equipment to wind motor coil and other similar products. This kind of motor coil winding machine is semi automatic winding machine, which is provided with flange to fix mold for winding coil. The flange of this model of motor coil winding machine is 500mm. The foot pedal of the motor coil winding machine can start and stop running the machine and switch the rotating direction, forward or reversely. The counter is adopted to record the number of turns.

Main features of motor coil winding machine MW500

• Slow starting, at the beginning of winding, the winding speed is very slow for safety
• Smooth running, during running, the motor coil winding machine is very stable
• Easy to operate, operating the motor coil winding machine is very easy and simple

Quick details of motor coil winding machine MW500

• Winding copper or aluminium wire
• Winding speed 200rpm
• Flange diameter 500mm
• Motor power 3kw
• One year warranty

Main Parameters

Typical standard specifications of motor coil winding machine MW500 are shown below, however, the winding machine can also be manufactured as requested.

Fig 1: Motor coil winding machine MW500's full view

Fig 2: Motor coil winding machine MW500's control board
