Semi Automatic Electric Conductor Wire Winder Motor Coil Winding Machine

Description of motor coil winding machine MW150

Semi automatic coil winding machine MW150 can be used to wind different sizes of copper wires or aluminium wires. The motor coil winding machine is mainly used to wind motor coil and other similar products. The motor coil winding machine is provided with main winding motor, flange, foot pedal, counter, control board, gear box, and electrical cabinet. The winding fixture can be mounted on the flange. The diameter of the flange is 150mm. The motor coil winding machine features strong force, high winding speed and easy to operate.

Quick details of motor coil winding machine MW150

• Slow starting
• Smooth running
• Strong pulling force
• High speed
• Simply structure
• Easy operating

Main parameters of motor coil winding machine MW150

Typical standard specifications of motor coil winding machine MW150 are shown below, however the winding machine can also be manufactured as requested.

Fig 1: Motor coil winding machine MW150's full view

Fig 2: Motor coil winding machine MW150's control board
