Semi Automatic Electric Conductor Wire Winder Motor Coil

Semi Automatic Electric Conductor Wire Winder Motor Coil

Semi Automatic Electric Conductor Wire Winder Motor Coil
Semi Automatic Electric Conductor Wire Winder Motor Coil

Large Image :  Semi Automatic Electric Conductor Wire Winder Motor Coil Get Best Price

Product Details:
Place of Origin: China
Brand Name: STT
Model Number: MW150
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: seaworthy packing
Delivery Time: 20 days
Payment Terms: T/T, L/C
Supply Ability: 100 sets per year
Detailed Product Description
Product Name: Motor Coil Winding Machine Usage: Winding Motor Coils
Flange Diameter: 150mm Color: As Requested
Winding Power: 2.2kw Winding Speed: 400rpm, Maximum
Height: 1400mm Warranty: 12 Months
High Light:

Electric Conductor Wire Winder

,

Motor Coil Wire Winder

,

Semi Automatic Electric Wire Winder

Semi Automatic Electric Conductor Wire Winder Motor Coil Winding Machine





Description of motor coil winding machine MW150



Semi automatic coil winding machine MW150 can be used to wind different sizes of copper wires or aluminium wires. The motor coil winding machine is mainly used to wind motor coil and other similar products. The motor coil winding machine is provided with main winding motor, flange, foot pedal, counter, control board, gear box, and electrical cabinet. The winding fixture can be mounted on the flange. The diameter of the flange is 150mm. The motor coil winding machine features strong force, high winding speed and easy to operate.





Quick details of motor coil winding machine MW150

  • Slow starting
  • Smooth running
  • Strong pulling force
  • High speed
  • Simply structure
  • Easy operating



Main parameters of motor coil winding machine MW150



Typical standard specifications of motor coil winding machine MW150 are shown below, however the winding machine can also be manufactured as requested.

Total Height: 1400mm
Flange Diameter: Ø150mm
Winding Speed: 0 ~ 400rpm
Counting Range: 0 ~ 9999.9
Max. Loading Capacity: 200KG
Motor Power: 2.2KW
Colour: customized
Machine Dimension(LxWxH): 900x700x1400mm



Semi Automatic Electric Conductor Wire Winder Motor Coil 0

Fig 1: Motor coil winding machine MW150's full view



Semi Automatic Electric Conductor Wire Winder Motor Coil 1

Fig 2: Motor coil winding machine MW150's control board



Semi Automatic Electric Conductor Wire Winder Motor Coil 2Semi Automatic Electric Conductor Wire Winder Motor Coil 3Semi Automatic Electric Conductor Wire Winder Motor Coil 4Semi Automatic Electric Conductor Wire Winder Motor Coil 5Semi Automatic Electric Conductor Wire Winder Motor Coil 6Semi Automatic Electric Conductor Wire Winder Motor Coil 7Semi Automatic Electric Conductor Wire Winder Motor Coil 8Semi Automatic Electric Conductor Wire Winder Motor Coil 9
