Semi Automatic Electric Motor Coil Winding Machine 150mm Flange Diameter

Factory Direct Selling Semi Automatic Electric Motor Coil Winding Machine

Description of motor coil winding machine MW150

Motor coil winding machine MW150 is a professional wire winder for winding motor coils and other similar products. The motor coil winding machine can be used to wind different specifications of copper wires or aluminium wires. With a counter, the motor coil winding machine can count the turns when winding. The motor coil winding machine is provided with winding motor, flange with diameter 150mm for fixing winding head, foot pedal, counter, gear box, and electrical cabinet. The foot pedal can be used to start or stop running the machine and switch the winding direction. The motor coil winding machine features big torque, high winding speed and easy to operate.

Quick details of motor coil winding machine MW150

• Slow starting
• Smooth running
• Strong pulling force
• High speed
• Simply structure
• Easy operating

Main parameters of motor coil winding machine MW150

Typical standard specifications of motor coil winding machine MW150 are shown below, however, the winding machine can also be manufactured as requested.

Fig 1: Motor coil winding machine MW150's full view

Fig 2: Motor coil winding machine MW150's control board
