Silicon Steel Sheet Transformer Core Cutting Machine PLC Control

PLC Control Silicon Steel Sheet Cut To Length Line Transformer Core Cutting Machine

Description of transformer core cutting machine HJX300-LL

Automatic transformer core cutting machine HJX300-LL is a professional cutting equipment for cutting silicon steel sheet to make transformer iron core or other similar products. The transformer core cutting machine can be used to cut the the silicon steel sheet with maximum width 300mm. The transformer core cutting machine can cut beveled edges at both ends and punch the silicon steel to make two holes and a V-notch on the silicon steel. With the control system based on PLC, the transformer core cutting machine can cut the silicon steel sheet according to the parameters preset. The transformer core cutting machine features easy operation and smooth running etc.

Quick details of transformer core cutting machine HJX300-LL

• Silicon steel sheet thickness 0.2 ~ 0.35mm
• Silicon steel sheet width 40 ~ 300mm
• Feeding speed 120m/min
• Motor power 11kw
• Color as requested
• 12 months warranty period

Main parameters of transformer core cutting machine HJX300-LL

The standard specifications of transformer core cutting machine HJX300-LL is shown below, however, the transformer core cutting machine can also be manufactured as requested.

Fig 1: Transformer core cutting machine HJX300-LLB's side view

Fig 2: Transformer core cutting machine HJX300-LLB's dereeler
