Description of copper foil winding machine JJ-BRJ600-2-2

Copper foil winding machine JJ-BRJ600-2-2 is one kind of simple and cheap foil winding machine. This kind of copper foil winding machine can wind copper or aluminium foil to making reactor coils and other similar products. The copper foil winding machine can wind one or two layers of foil with max width 600mm and one or two layers of insulation paper. The copper foil winding machine can count the number of turns wound when winding. The foot pedal can be used to switch the rotating direction of the main shaft. Mechanical rectifying system is used to make the foil edge neat when winding. The copper foil winding machine can be operated easily.

Main components of copper foil winding machine JJ-BRJ600-2-2

1. Main frame

2. Foil decoiler

3. Winding unit

4. Insulation decoiler

5. Pneumatic devices

6. Electrical control system

Technical parameters of copper foil winding machine JJ-BRJ600-2-2

Typical standard specifications of copper foil winding machine JJ-BRJ600-2-2 are shown below, however, the copper foil winding machine can also be manufactured as requested.



Fig 1: Copper foil winding machine JJ-BRJ600-2-2's front view


Fig 2: Copper foil winding machine JJ-BRJ600-2-2's foil decoilers
