Wire Winder Electric 3 Kw Motor Coil Winding Machine 1400mm Height

Easy Operated Cheap Wire Winder Electric Motor Coil Winding Machine

Description of motor coil winding machine MW1200

Electric motor coil winding machine MW1200 is operated easily and mainly used to wind motor coils and other similar products. The motor coil winding machine is equipped with an adjustable movable mold, which can be used to mount a wire mould on the upper and lower movable blocks with long screws respectively. Turning a screw rods of the movable parts, the height of the wire mould can be adjusted with range from 150mm to 1200mm, with this, the motor coil winding machine can be used to wind different size of copper or aluminium wire to make the motor coil.

Quick details of motor coil winding machine

• Motor power 3 kw
• Machine height 1400mm
• Rotating speed 0 ~ 80rpm
• Smooth running
• Adjustable blocks
• Simply structure

Main Parameters of motor coil winding machine MW1200

Typical standard specifications of motor coil winding machine MW1200 are shown below and the machine can also be manufactured as requested.

Fig 1: Motor coil winding machine MW1200's full view

Fig 2: Motor coil winding machine MW1200's controller
