Cast Resin Copper Transformer Making Equipment Two Layers

Cast Resin Transformer Making Equipment Two Layers Copper Foil Winding Machine

Introduction of copper foil winding machine BRJ1600-2

Copper foil winding machine BRJ1600-2 is one of foil winders. The copper foil winding machine is mainly used for winding cast resin transformer’s foil coils and other similar products. The foil winding machine can be used to wind both copper foil and aluminum foil and can wind one or two layers of foil conductors and one or two layers of insulation paper. The copper foil winding machine is provided with TIG welding unit, including winding machine, cooler, jig plat and so on, to weld bus bar with foil together. Photoelectric sensors are adopted in the copper foil winding machine to correct the position of foil when the foil is wound. Control system of the copper foil winding machine is based on PLC. With a touch screen, it is very easy to operate the copper foil winding machine.

Features of copper foil winding machine BRJ1600-2

• Slow starting
• Running smooth
• High automation
• Full function
• Big power
• Neat foil edge
• Tight winding
• Easy operation

Main components of copper foil winding machine BRJ1600-2

• Main frame, strong structure
• Winding unit, 30kw motor driving
• Insulation decoiler, with high tension
• Cleaning system, pneumatic driving
• Cutting system, pneumatic driving
• Foil deburring system
• Edge alignment system, photoelectric sensing
• Automatic welding unit, TIG
• Electronic control system
• Pneumatic system

Technical Parameters of copper foil winding machine BRJ1600-2

Typical standard specifications of copper foil winding machine BRJ1600-2 are shown below, however, the copper foil winding machine can also be manufactured as requested.

Fig 1: Copper foil winding machine BRJ1600-2's front view

Fig 2: Copper foil winding machine BRJ1600-2's TIG welding unit
