Description of copper foil winding machine BRJ1200-2

Low voltage transformer copper foil winding machine BRJ1200-2 can handle:

• Two layers of copper foil strip with thickness from 0.2 mm to 2.0mm
• Two layers of Aluminium foil strip with thickness from 0.3mm to 3.0 mm
• Maximum foil width 1200mm
• Two layers of foil
• Two layers of insulation paper
• Big power 22kw motor

The copper foil winding machine is provided with

• Two sets of foil decoilers
• Two insulation decoilers
• Photoelectric sensors
• Pressing rollers
• Control system based on PLC
• Touch screen
• Foot pedal, which can switch the rotating direction
• TIG welding unit

Main Components of copper foil winding machine BRJ1200-2

• Main frame
• Winding unit
• Foil decoiler
• Insulation decoiler
• End-fill strip feeder
• Cleaning system
• Cutting system
• Edge alignment system
• Automatic welding unit
• Electronic control system

Technical Parameters of copper foil winding machine BRJ1200-2

Typical standard specifications of copper foil winding machine BRJ1200-2 are shown below, however the foil winding machine can also be manufactured as requested.

Fig 1: Copper foil winding machine BRJ1200-2's side view

Fig 2: Copper foil winding machine BRJ1200-2's back view
