Introduction of automatic coil winding machine LR200

Automatic flat wire coil winding machine LR200 is a professional equipment for winding flat copper or aluminum wires to make different shapes and sizes of coil. The vertical coil winding machine bends wire when winding to avoid the finished coil deforming. These finished coils can be used in reactors and other similar products. The vertical coil winding machine features high automation, slow starting, smooth running, high automation, strong rotating force, and easy to operate, etc.

Main components of automatic coil winding machine LR200

1. Main Frame
2. Touch screen
3. Electrical Control Cabinet
4. Pneumatic System
5. Foot Pedal

Main parameters of automatic coil winding machine LR200

Typical standard specifications of LR200 are shown below, however these can be easily modified as requested.

Fig 1: Automatic coil winding machine LR200's front view

Fig 2: Automatic coil winding machine LR200's coil stand
