Automatic Core Slitting Machine CRGO Silicon Steel Sheet Making Strip Coil

Automatic Core Slitting Machine CRGO Silicon Steel Sheet Slitter Making Strip Coil

Description of core slitting machine ZJX1250

Automatic core slitting machine ZJX1250 is a professional equipment to slit silicon steel sheet to make different width of strip coil. The slitting speed of the core slitting machine can be adjusted. The core slitting machine is provided with 6 sets of cutters, which can cut five strips at one time. The core slitting machine features easy operation and precise cutting.

Quick details of core slitting machine ZJX1250

• Decoiler expanding range Ø470 ~ 520mm
• Sheet width 500 ~ 1250 mm
• Sheet thickness 0.15 ~ 0.6mm
• 6 sets of cutters
• Feeding speed 120m/min
• Power 46kw
• One year warranty

Main components of core slitting machine ZJX1250

1. Trolley for loading and unloading material

2. Decoiler

3. Material receiver

4. Movable guide device

5. Slitting device

6. Tensioner

7. Winder

8. Hydraulic station and pneumatic system

9. Electrical control cabinet and console

Main parameters of core slitting machine ZJX1250

Typical standard specifications of core slitting machine ZJX1250 are shown below, however, the core slitting machine can also be manufactured as requested.

Fig 1: Core slitting machine ZJX1250's front view

Fig 2: Core slitting machine ZJX1250's winder
