| Name: | Motor Coil Winding Machine | Function: | Winding Motor Coil |
|---|---|---|---|
| Flange Diameter: | 150mm | Color: | Optional |
| Motor Power: | 2.2kw | Rotating Speed: | 400rpm |
| Machine Height: | 1400mm | Warranty: | 12 Months |
| High Light: | Easy Operation Motor Coil Winding Machine,Copper Wire Coil Winding Machine,Three Phase Motor Coil Winding Machine |
||
Easy Operation Copper Wire Winder Three Phase Motor Coil Winding Machine
Description of motor coil winding machine MW150
Motor coil winding machine MW150 is one kind of winding machine for winding different kinds of motor with different former. The coil winding machine can be used to wind different size copper or aluminium wire to make different kinds of motor coil or other similar products. The motor coil winding machine is provided with main strong steel frame, flange, foot pedal, counter, control board, winding motor, gear box, and electrical cabinet. The former can be mounted on the flange with diameter 150mm. The motor coil winding machine features strong force, high winding speed and easy operation, etc..
Quick details of motor coil winding machine MW150
Main parameters of motor coil winding machine MW150
Typical standard specifications of motor coil winding machine MW150 are shown below, however, the machine can also be made as requested.
| Machine Height: | 1400mm |
| Flange Diameter: | 150mm |
| Winding Speed: | 0 ~ 400rpm |
| Counting Range: | 0 ~ 9999.9 |
| Max. Loading Capacity: | 500KG |
| Motor Power: | 2.2KW |
| Colour: | customized |
| Machine Dimension(LxWxH): | 900x700x1400mm |
Fig 1: Motor coil winding machine MW150's full view
Fig 2: Motor coil winding machine MW150's control board
