CRGO Transformer Core Cutting Machine Making Core Leg

CRGO Transformer Core Cutting Machine Making Core Leg

CRGO Transformer Core Cutting Machine Making Core Leg
CRGO Transformer Core Cutting Machine Making Core Leg

Large Image :  CRGO Transformer Core Cutting Machine Making Core Leg Get Best Price

Product Details:
Place of Origin: China
Brand Name: STT
Model Number: ZZ400
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: seaworthy packing
Delivery Time: 90 days
Payment Terms: T/T, L/C
Supply Ability: 100 sets per year
Detailed Product Description
Product Name: Transformer Core Cutting Machine Function: Making Core Leg
Sheet Thickness: 0.2~0.35mm Sheet Width: 40 ~400mm
Motor Power: 14kw Feed Speed: 180m/min
Machine Color: Customizable Warranty: 12 Months
High Light:

14kw CRGO Core Cutting Machine

,

CRGO Transformer Core Cutting Machine

,

180m/min CRGO Core Cutting Machine

Good Price CRGO Transformer Core Cutting Machine Making Core Leg





Description of transformer core cutting machine ZZ400



Transformer core cutting machine ZZ400 is a special cutting machine for cutting silicon steel sheet to make core legs for transformer iron core. This kind of transformer core cutting machine can be used to cut the iron core sheet with maximum width 400mm and can cut different shapes of the core legs, such as equilateral core leg, eccentric center core leg, etc. The transformer core cutting machine features easy operation, high production effective and so on. With the control system based on PLC, the transformer core cutting machine is with high automation.





Quick details of transformer core cutting machine ZZ400



Sheet thickness 0.2 ~ 0.35mm

Sheet width 40 ~ 400mm

Feeding speed 180m/min

Power 14kw





Technical parameters of transformer core cutting machine ZZ400



Typical standard specifications of transformer core cutting machine ZZ400 are shown below, however, the transformer core cutting machine is also can be manufactured as requested.

Roll Material Width Tolerance: ≤±0.1mm
Roll Material Burr Length: ≤0.02mm
Sheet Thickness: 0.2~‌0.35mm
Sheet Width: 40~300mm
Sheet Length: 150~2500mm
Feeding speed: 0~180m/min
Power: 14Kw



CRGO Transformer Core Cutting Machine Making Core Leg 0

Fig 1: Transformer core cutting machine TZZ400's full view

CRGO Transformer Core Cutting Machine Making Core Leg 1

Fig 2: Transformer core cutting machine TZZ400's side view



CRGO Transformer Core Cutting Machine Making Core Leg 2

CRGO Transformer Core Cutting Machine Making Core Leg 3CRGO Transformer Core Cutting Machine Making Core Leg 4CRGO Transformer Core Cutting Machine Making Core Leg 5CRGO Transformer Core Cutting Machine Making Core Leg 6CRGO Transformer Core Cutting Machine Making Core Leg 7CRGO Transformer Core Cutting Machine Making Core Leg 8
