Description of transformer core cutting machine of ZZ400-BK

Transformer core cutting machine ZZ400-BK is a special cutter and can cut the different length strip with same difference (step lap type). The transformer core cutting machine is mainly used to cut the silicon steel to make center legs of transformer core. The transformer core cutting machine is provided with a cutting unit and punching unit to cut the silicon steel and punch holes on the cut sheet as requested. The core cutting machine can cut the silicon steel with maximum width 400mm. The core cutting machine can make step lap center legs. The transformer core cutting machine’s control system is based on PLC, which make it be operated easily.

Main components of transformer core cutting machine ZZ400-BK

• Single head hydraulic dereeler
• Slope guide device
• Punching and cutting devices
• Conveyor
• Pneumatic system
• PLC control system

Main parameters of transformer core cutting machine ZZ400-BK

The following is the standard specifications of the transformer core cutting machine ZZ400-BK and the transformer core cutting machine can also be manufactured as requested.

Fig 1: Transformer core cutting machine ZZ400-BK's full view

Fig 2: Transformer core cutting machine ZZ400-BK's cutter
