Powerful 3kw Motor Power Coil Winding Machine 1400mm Height For Motor Coils

1 set
MOQ
negotiable
Price
Powerful 3kw Motor Power Coil Winding Machine 1400mm Height For Motor Coils
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Motor Coil Winding Machine
Usage: Winding Motor Coil
Adjustable Mould: 1 Pc
Color: As Requested
Motor Power: 3kw
Winding Speed: 0 ~ 200rpm
Machine Height: 1400mm
Warranty: 12 Months
Highlight:

Powerful Motor Coil Winding Machine

,

3kw Motor Coil Winding Machine

,

1400mm Motor Coil Winding Machine

Basic Infomation
Place of Origin: China
Brand Name: STT
Model Number: MW800
Payment & Shipping Terms
Packaging Details: seaworthy packing
Delivery Time: 20 days
Payment Terms: T/T, L/C
Supply Ability: 100 sets per year
Product Description

Máquina de bobinado de bobinas de motor Coil Winding Machine





Description of motor coil winding machine MW800



Motor coil winding machine MW800 is a professional winding machine for winding motor coils and other similar products. This kind winding machine can be used to wind copper wire or aluminium wire. With a counter, the motor coil winding machine can count the number of turns when winding. The adjustable mold of the motor coil winding machine can be used to mount different kind of winding arbors to make different coils. The motor coil winding machine’s foot pedal is with functions of stop or starting running machine and switching rotating direction.





Quick details of motor coil winding machine MW800

  • Slow starting, when the machine begins to run, the rotating is very slow for sage
  • Smooth running, during running, the performance of the machine is very high
  • Strong pulling force, with 2.2kw motor, the machine is with a strong pulling force
  • High speed, the max winding sped can reach 200 rpm
  • Simply structure, with this, the machine features easy maintaining
  • Easy operating, it is very easy to operate the machine, just need to input the parameters and press the foot pedal



Main parameters of motor coil winding machine MW800



Typical standard specifications of motor coil winding machine MW800 are shown below and the coil winding machine can also be manufactured as requested.

Machine Height: 1400mm
Mold Expansible Range: 150 ~ 800mm
Max Winding Speed: 0 ~ 200 rpm
Counting Range: 0 ~ 9999.9
Max. Loading Capacity: 500KG
Winding Motor Power: 3KW
Machine Colour: As requested
Machine Dimension(LxWxH): 900x700x1400mm



Powerful 3kw Motor Power Coil Winding Machine 1400mm Height For Motor Coils 0

Fig 1: Motor coil winding machine MW800's full view



Powerful 3kw Motor Power Coil Winding Machine 1400mm Height For Motor Coils 1

Fig 2: Motor coil winding machine MW800's control board



Powerful 3kw Motor Power Coil Winding Machine 1400mm Height For Motor Coils 2Powerful 3kw Motor Power Coil Winding Machine 1400mm Height For Motor Coils 3Powerful 3kw Motor Power Coil Winding Machine 1400mm Height For Motor Coils 4Powerful 3kw Motor Power Coil Winding Machine 1400mm Height For Motor Coils 5Powerful 3kw Motor Power Coil Winding Machine 1400mm Height For Motor Coils 6Powerful 3kw Motor Power Coil Winding Machine 1400mm Height For Motor Coils 7Powerful 3kw Motor Power Coil Winding Machine 1400mm Height For Motor Coils 8Powerful 3kw Motor Power Coil Winding Machine 1400mm Height For Motor Coils 9Powerful 3kw Motor Power Coil Winding Machine 1400mm Height For Motor Coils 10
