Description of motor coil winding machine MW1200

Motor coil winding machine MW1200 is a special winder equipment for winding motor coils or other similar products. The motor coil winding machine can be used to wind both copper wire and aluminium wire. With an adjustable mold, the motor coil winding machine can wind different sizes of coils. The adjustable mold is with two movable blocks and the winding former can be mounted on these two blocks. The distance between the two blocks can be adjusted and the adjustable range is from 150mm to 1200mm. The motor coil winding machine is provided with a counter and it can count the number of turns when winding. The motor coil winding machine features slow starting, smooth windign and easy operation etc.

Quick details of motor coil winding machine MW1200

§ Motor power 4kw

§ Machine body height 1400mm

§ Winding speed 0 ~ 80rpm

§ Smooth running

§ Adjustable blocks

§ Simply structure

Main parameters of motor coil winding machine MW1200

Typical standard specifications of motor coil winding machine MW1200 are shown below and the motor coil winding machine can also be manufactured as requested.

Fig 1: Motor coil winding machine MW1200's full view

Fig 2: Motor coil winding machine MW1200's control board
