Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core

Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core

Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core
Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core

Large Image :  Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core Get Best Price

Product Details:
Place of Origin: China
Brand Name: STT
Model Number: ZZ300
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: seaworthy packing
Delivery Time: 90 days
Payment Terms: T/T, L/C
Supply Ability: 100 sets per year
Detailed Product Description
Machine Name: Transformer Core Cutting Machines Function: Making Transformer Center Post
Sheet Width: 40 ~ 300mm Sheet Thickness: 0.23 ~ 0.35mm
Feeding Speed: 180m/min Motor Power: 14kw
Color: Customizable Warranty Period: 12 Months
High Light:

Automatic Transformer Core Cutting Machine

,

Silicon Steel Transformer Core Cutting Machine

,

Automatic Core Cutting Machine 180m/min

Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core Centre Pillar





Description of automatic core cutting machine ZZ300



Automatic core cutting machine ZZ300 is a professional cutting equipment to cut silicon steel to make transformer core centre pillar. The automatic core cutting machine can be used to cut the silicon steel with maximum thickness 0.35mm and the maximum width 300mm. The core cutting machine is provided with decoiler for placing supply coil with diameter 500mm and the capacity of the decoiler is 1500kg. The feeding speed of the automatic core cutting machine is 180m/min. The total power is 14kw. The automatic core cutting machine features easy operation.





Quick details of automatic core cutting machine ZZ300



  • Sheet thickness 0.2 ~ 0.35mm
  • Sheet width 40 ~ 300mm
  • Feeding speed 180m/min
  • Power 14kw



Technical parameters of automatic core cutting machine ZZ300



Typical standard specifications of automatic core cutting machine ZZ300 are shown below, however, the core cutting machine can also be manufactured as requested.

Roll Material Width Tolerance: ≤±0.1mm
Roll Material Burr Length: ≤0.02mm
Sheet Thickness: 0.2~‌0.35mm
Sheet Width: 40~300mm
Sheet Length: 150~2500mm
Cutting speed: 0~180m/min
Motor Power: 14Kw



Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core 0

Fig 1: Automatic core cutting machine ZZ300's full view



Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core 1

Fig 2: Automatic core cutting machine ZZ300's side view



Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core 2Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core 3Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core 4Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core 5

Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core 6Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core 7Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core 8Automatic Core Cutting Machine Cutting Silicon Steel To Make Transformer Core 9
