Simply Wire Winder Semi Automatic Transformer Coil Winding Machine

1
MOQ
USD2000 ~ 4000 per set
Price
Simply Wire Winder Semi Automatic Transformer Coil Winding Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Transformer Coil Winding Machine
Usage: Winding Wire Coil
Center Heigth: 1000mm
Winding Shaft: 40x40mm
Tailstock: Split Type
Machine Color: As Requested
Counter: Digital Type
Winding Speed: 0 ~ 200rpm
Highlight:

semi automatic transformer coil winder

,

wire winding machine for transformers

,

transformer coil winding machine with warranty
Basic Infomation
Place of Origin: China
Brand Name: STT
Certification: CE
Model Number: GDY-1T
Payment & Shipping Terms
Packaging Details: seaworthy packing
Delivery Time: 20 days
Payment Terms: T/T,L/C
Supply Ability: 100 sets per year
Product Description
Simply Wire Winder Semi Automatic Transformer Coil Winding Machine
The Simply Wire Winder Semi Automatic Transformer Coil Winding Machine GDY-1T is a versatile winding solution designed for transformer coil production. This robust machine efficiently handles both copper and aluminum wire winding applications, making it ideal for transformer manufacturing and similar industrial processes.
Key Features
  • Compatible with both copper and aluminum wire winding
  • Maximum winding width: 800mm
  • Maximum capacity: 1000kg
  • Winding power: 3kW
  • Winding shaft size: 40x40x1000mm
  • Two-speed gear system
  • Integrated counter for precise turn counting
  • Adjustable winding speed via potentiometer control
  • Foot pedal for convenient rotation direction switching
  • User-friendly operation and intuitive controls
Technical Specifications
Specification Value
Center Height 1000mm
Shaft Size 40x40x1000mm
Flange Square Hole Size 40x40mm
Winding Speed 0 - 200rpm
Speed Gear 2 pcs
Maximum Winding Width 800mm
Counting Range 0 - 9999.9
Maximum Capacity 1000KG
Power 3KW
Total Weight 500 kg
Dimension (LxWxH) 2800x700x1400mm
Product Images
Simply Wire Winder Semi Automatic Transformer Coil Winding Machine  0
Fig 1: Transformer coil winding machine GDY-1T's full view
Simply Wire Winder Semi Automatic Transformer Coil Winding Machine  1
Fig 2: Transformer coil winding machine GDY-1T's tailstock
Simply Wire Winder Semi Automatic Transformer Coil Winding Machine  2
Simply Wire Winder Semi Automatic Transformer Coil Winding Machine  3
Simply Wire Winder Semi Automatic Transformer Coil Winding Machine  4
Simply Wire Winder Semi Automatic Transformer Coil Winding Machine  5
