Transformer Foil Winding Machine with 15kW Winding Motor, 480-520mm Decoiler Diameter, and Optional Machine Color

Product Description:

Transformer Foil Winding Machine, is a highly advanced piece of equipment designed specifically for the precise and efficient winding of copper or aliminium foil used in transformer manufacturing. The foil winding machine is engineered to meet the rigorous demands of modern transformer production, offering unmatched reliability, accuracy, and ease of operation. Its robust design and cutting-edge technology make it an indispensable tool for manufacturers aiming to produce high-quality transformers with consistent performance.

One of the standout features of the Foil Winding Machine is its decoiler diameter range, which spans from 480mm to 520mm. This wide range allows the machine to accommodate the foil coils diameter 500mm. Whether you are working with smaller or larger coils, the Foil Winding Machine ensures smooth unwinding without any damage to the copper or aliminium foil, maintaining the integrity of the material throughout the winding process.

The foil winding machine is specifically designed to handle copper or aluminium foil widths ranging from 200mm to 1000mm. This broad width capacity allows manufacturers to work with a variety of copper foil specifications, catering to different transformer designs and applications. The precise control system integrated into the Foil Winding Machine guarantees that the foil is wound with exact tension and alignment, preventing wrinkles or misalignment that could compromise the transformer’s performance.

Powering the Foil Winding Machine is a robust 15kW winding motor, which provides ample torque and speed control to ensure consistent and smooth winding operations. This powerful motor not only enhances productivity but also contributes to the longevity of the machine by reducing mechanical strain and wear. Operators can easily adjust the winding parameters to suit specific production needs, making the Foil Winding Machine highly adaptable and user-friendly.

In terms of aesthetics and customization, the Transformer Foil Winding Machine offers optional machine color choices. This allows manufacturers to select a color that best fits their workshop environment or company branding. Such customization options add a touch of personalization to the machine without compromising its performance or functionality.

Reliability and customer satisfaction are paramount, which is why the Foil Winding Machine comes with a 12-month warranty period. This warranty ensures that any manufacturing defects or operational issues encountered within the first year are promptly addressed by the manufacturer, providing peace of mind and confidence in the machine’s quality. The dedicated after-sales support further enhances user experience by offering timely maintenance and technical assistance whenever needed.

The Transformer Foil Winding Winding Machine is an integral part of the transformer production process, making the winding of copper or aluminium foil more efficient, accurate, and reliable. Its advanced features and specifications are designed to meet the evolving needs of the electrical manufacturing industry. By investing in the Transformer Foil Winding Machine, manufacturers can significantly improve their production efficiency, reduce material waste, and ensure the consistent quality of their transformer products.

In summary, the Transformer Foil Winding Machine stands out as a top-tier solution for winding copper or aluminium foil with precision and ease. With a decoiler diameter range of 480 to 520mm, copper or aluminium foil width capacity between 200 and 1000mm, a powerful 15kW winding motor, optional machine color customization, and a comprehensive 12-month warranty, this foil winding machine is engineered to deliver exceptional performance and durability. Whether you are upgrading your current equipment or entering the transformer manufacturing industry, the Transformer Foil Winding Machine provides the reliability and efficiency you need to succeed.

Features:

• Product Name: Transformer Foil Winding Machine
• Foil Material: Copper or Aluminium
• Winding Power: 15kw
• Copper Foil Width: 200-1000mm
• Decoiler Diameter Range: 480 ~ 520mm
• Application: Transformer Manufacturing
• High precision and efficiency in Transformer Foil Winding Machine operations

Technical Parameters:

Applications:

The Transformer Foil Winding Machine, model BRJ1000-2, is an advanced piece of equipment designed specifically for precision foil winding applications in transformer manufacturing. Its versatility and high-performance features make it ideal for various industrial settings where efficient and accurate foil winding is essential. This Transformer Foil Winding Machine excels in handling both copper and aluminium foil materials, with copper foil widths ranging from 200mm to 1000mm and a foil conductor outer diameter (OD) of up to 1000mm, ensuring it meets diverse production requirements.

The Transformer Foil Winding Machine is widely used in transformer factories, electrical equipment manufacturing plants, and research institutions focusing on transformer design and production. Its electric scissors foil cutter allows for clean and precise cutting, improving the overall quality and efficiency of the winding process. The machine color is optional, allowing customization to match the branding or operational preferences of the user’s facility. With a supply capacity of 100 sets per year and a delivery time of 45 days, we ensures timely fulfillment of orders, backed by negotiable pricing and flexible payment terms via T/T.

In practical application scenarios, the Transformer Foil Winding Machine is indispensable during the production of power transformers, distribution transformers, and specialty transformers used in various industries such as energy, automotive, and electronics. Its precise winding capabilities help manufacturers achieve consistent electrical and mechanical properties in transformer foil windings, which are critical for performance and reliability. The machine’s seaworth packing guarantees safe delivery, even for international shipments, making it suitable for global enterprises looking to enhance their manufacturing lines with cutting-edge winding technology.

Furthermore, the Transformer Foil Winding Machine is also suitable for prototype development and small batch production due to its minimum order quantity of just one set. This flexibility allows research and development teams to experiment with different foil materials and winding parameters without committing to large-scale orders. Overall, the BRJ1000-2 model represents a reliable, efficient, and customizable solution for all transformer foil winding needs, providing users with a competitive edge in manufacturing high-quality transformer components.

Customization:

We offers customized Transformer Foil Winding Machine solutions tailored to your specific needs. Our model BRJ1000-2 Transformer Foil Winding Machine is designed for precision and efficiency in transformer manufacturing.

With a minimum order quantity of just 1 set, we provide flexible pricing options that are negotiable to suit your budget. The machine features an electric scissors foil cutter compatible with copper foil widths ranging from 200 to 1000mm, ensuring accurate and clean cuts every time.

The Transformer Foil Winding Machine operates at a welder speed of 0.8m/min and supports a power supply of 3-phase 380V, 50Hz (default) and other different voltages, making it adaptable to various production environments. We guarantee a supply ability of 100 sets per year, with a delivery time of 45 days and secure seaworth packing for safe transportation.

Payment terms are convenient with T/T options available. Trust our Transformer Foil Winding Machine to enhance your transformer manufacturing process with reliable performance and customizable features.

Support and Services:

Our Transformer Foil Winding Machine is designed to provide precise and efficient winding solutions for transformer manufacturing. For technical support, please ensure you have the machine model number and serial number ready when seeking assistance.

We offer comprehensive services including installation guidance, routine maintenance, troubleshooting, and repair support to ensure optimal performance of your winding machine.

Our technical team is equipped to help with technical support on site or on line to maximize the machine’s productivity and longevity. For any operational issues, please refer to the user manual for initial troubleshooting steps. If further assistance is required, our support staff can provide detailed diagnostics and recommend corrective actions. We also provide replacement parts and consumables tailored specifically for the Transformer Foil Winding Machine to maintain consistent output quality. Regular servicing and preventive maintenance are recommended to avoid unexpected downtime and to extend the lifespan of your equipment.

By choosing our technical support services, you ensure that your Transformer Foil Winding Machine remains reliable and efficient throughout its operational life.

Packing and Shipping:

Product Packaging:

The Transformer Foil Winding Machine is carefully packed to ensure it arrives at your facility in perfect condition. Each unit is securely wrapped with stretch film to prevent any damage during transit. All packaging materials are chosen to provide maximum protection against moisture, dust, and mechanical impact.

Shipping:

We offer worldwide shipping options for the Transformer Foil Winding Machine. The shipment is handled by experienced logistics partners who ensure timely and safe delivery. Depending on your location and requirement, we provide various shipping methods including sea freight, and land transport. Tracking information will be provided once the product is dispatched. Additionally, we assist with all necessary export documentation to facilitate smooth customs clearance.

FAQ:

Q1: What is the brand and model number of the Transformer Foil Winding Machine?

A1: The Transformer Foil Winding Machine is manufactured by STT, and the model number is BRJ1000-2.

Q2: What is the minimum order quantity for this machine?

A2: The minimum order quantity for the Transformer Foil Winding Machine is 1 set.

Q3: What payment terms are accepted for purchasing the machine?

A3: The accepted payment term for this product is T/T (Telegraphic Transfer).

Q4: How long does it take to deliver the Transformer Foil Winding Machine after placing an order?

A4: The delivery time for the machine is approximately 45 days after the order is confirmed.

Q5: What are the packaging details for shipping the Transformer Foil Winding Machine?

A5: The machine is packaged using seaworth packing to ensure safe delivery.

Q6: What is the supply ability of the Transformer Foil Winding Machine per year?

A6: The supplier can provide up to 100 sets of the Transformer Foil Winding Machine in one year.

Q7: Is the price for the Transformer Foil Winding Machine fixed or negotiable?

A7: The price for the machine is negotiable. Please contact the supplier for a detailed quotation.
