5.5KW Winding Motor Transformer Coil Winding Machine with 900mm Shaft Height and 1000mm Winding Width

5.5kw Winding Motor Power Coil Winder Machine Featuring 900mm Shaft Height Suitable for Wire Coil Manufacturing Processes

Product Description:

The Transformer Coil Winding Machine ZPX1000 is a state-of-the-art solution designed to meet the demanding requirements of modern transformer manufacturing. Engineered with precision and robustness, this Coil Winder Machine stands out as an essential piece of equipment for producing high-quality transformer coils with consistent accuracy and efficiency. Whether you are working with copper or aluminium wire materials, this machine delivers exceptional performance tailored to your production needs.

At the heart of this Transformer Coil Winder is a powerful 15.5KW winding motor that ensures smooth and reliable operation. The motor's strength allows the machine to handle heavy-duty winding tasks without compromising speed or precision. This makes the coil winding machine ideal for industrial applications where productivity and quality are paramount. The automatic features integrated into the machine further enhance its efficiency, reducing manual intervention and minimizing the risk of errors.

One of the key advantages of this Automatic Coil Winding Machine is its impressive winding capacity. It can accommodate up to 1000mm winding width, making it suitable for a wide range of transformer coil specifications. This capability allows manufacturers to produce coils that meet diverse electrical and mechanical requirements, supporting various transformer designs and applications. The machine’s adaptability to both copper and aluminium wire materials adds to its versatility, catering to different industry standards and customer preferences.

Durability and ease of maintenance are also significant considerations in the design of this Coil Winder Machine. Built with high-quality materials and precision engineering, it ensures long-lasting service life even under continuous industrial use. The automatic functions not only improve winding accuracy but also simplify the operation process, enabling operators to focus on quality control and other critical tasks. This combination of automation and robust construction results in a machine that boosts productivity while maintaining excellent coil winding standards.

Moreover, the Transformer Coil Winder’s user-friendly interface and controls make it accessible to operators of varying skill levels. The intuitive design reduces the learning curve and helps minimize downtime, contributing to a more streamlined production workflow. Whether you are manufacturing small batches or large volumes of transformer coils, this Automatic Coil Winding Machine provides the consistency and reliability necessary to meet tight production schedules and stringent quality requirements.

In summary, the Transformer Coil Winding Machine is an indispensable tool for any transformer manufacturing facility seeking to enhance their coil production capabilities. With its powerful 5.5KW motor, ability to handle copper or aluminium wire materials, and winding width up to 1000mm, it offers unmatched performance and flexibility. The compact dimensions and generous shaft height further add to its practicality, while the automatic winding features ensure precision and efficiency. Investing in this Coil Winder Machine means embracing innovation and quality, ultimately leading to superior transformer coils and improved operational productivity.

Features:

• Product Name: Transformer Coil Winding Machine
• Shaft Size: 40x40mm
• Material Compatibility: Copper and Aluminum Wires
• Warranty: 12 Months
• Power: 5.5kw Motor
• High precision Transformer Coil Winder for efficient winding
• Advanced Motor Coil Winding Machine designed for durability and performance
• Reliable Electrical Coil Winding Equipment suitable for various industrial applications

Technical Parameters:

Applications:

The Transformer Coil Winding Machine, also known as the Transformer Coil Winder or CNC Coil Winding Machine, is an essential piece of equipment designed for precision winding of transformer coils. Manufactured in China and available under OEM or custom brand options, this machine is perfect for a wide range of industrial and manufacturing applications where high efficiency and accuracy are paramount. Certified by CE, it guarantees quality and reliability for professional use.

This machine is ideal for transformer manufacturers, electrical component producers, and repair workshops that require a robust and versatile solution for coil winding. With a shaft height of 900mm and a winding width up to 1000mm, it can handle various transformer sizes and specifications, making it suitable for both small-scale and large-scale production environments. The powerful 5.5KW winding motor combined with a 0.75KW servo motor power ensures smooth, consistent, and high-speed operation, significantly enhancing productivity.

Typical application occasions for the Transformer Coil Winder include the production of power transformers, distribution transformers, instrument transformers, and other electromagnetic coils used in electrical equipment. It is also widely used in research and development laboratories for prototype winding and testing, as well as in educational institutions for training purposes. The CNC Coil Winding Machine’s precision control system allows for complex winding patterns, making it indispensable for modern transformer manufacturing lines.

In terms of packaging and delivery, the Transformer Coil Winding Machine is shipped in export wooden cases to ensure safe transport. The delivery time of the machine is 30–35 days. With a minimum order quantity of just one set and a competitive price range between USD 8,000 and 15,000 per set, it offers excellent value for businesses of all sizes. Payment terms are flexible and include T/T.

Thanks to a supply ability of 100 sets per year, customers can rely on consistent availability to support their production schedules. Whether you are upgrading your existing machinery or setting up a new production line, the Transformer Coil Winding Machine provides a reliable, high-performance solution for all your transformer coil winding needs.

Customization:

Our Transformer Coil Winding Machine offers comprehensive product customization services tailored to meet your specific needs. Manufactured under OEM or custom brand options in China, this equipment is certified with CE, ensuring high quality and reliability. With a minimum order quantity of just 1 set, you can easily acquire this advanced Transformer Winding Machine.

Priced between USD 8,000 and 15,000 per set, the Wire Coil Winding Machine comes with secure packaging options including export wooden cases to ensure safe delivery.

Payment terms are flexible, accepting T/T. Our supply ability reaches up to 100 sets per year, allowing us to meet both small and large scale demands efficiently. The Electrical Coil Winding Equipment supports a maximum of 1 finished coil with a shaft height of 900 mm. The machine is compatible with copper or aluminium wire materials, offering versatility for different winding applications. Each unit comes with a 12-month warranty, providing assurance of product durability and customer support.

Support and Services:

Our Transformer Coil Winding Machine is designed to provide precision, efficiency, and reliability in the manufacturing of transformer coils. To ensure optimal performance and longevity of your machine, we offer comprehensive technical support and services.

Technical Support:

Our expert technical support team is available to assist you with installation, setup, and troubleshooting. We provide detailed user manuals and operational guidance to help you understand all features and functions of the machine. In case of any operational issues, our support staff can guide you through step-by-step solutions to minimize downtime.

Maintenance Services:

Regular maintenance is crucial for the smooth operation of the Transformer Coil Winding Machine. We offer scheduled maintenance services including inspection, calibration, cleaning, and replacement of worn-out parts. Our maintenance programs are designed to extend the life of your equipment and maintain high precision in winding operations.

Training and Consultation:

To maximize the benefits of your machine, we provide training sessions for your operators and technicians. These sessions cover machine operation, safety protocols, and basic troubleshooting techniques. Additionally, our consultants can advise on optimizing your winding processes for improved efficiency and quality.

Spare Parts and Upgrades:

We supply genuine spare parts and accessories to ensure compatibility and performance. Our product upgrade services help you keep your machine up-to-date with the latest technology improvements and features.

Warranty and Repair:

The Transformer Coil Winding Machine comes with a standard warranty covering manufacturing defects. In the event of a malfunction, our repair services are available to restore your machine to full working condition promptly and professionally.

Customer satisfaction is our priority. We are committed to providing reliable technical support and high-quality services to help you achieve the best results with your Transformer Coil Winding Machine.

Packing and Shipping:

Product Packaging:

The Transformer Coil Winding Machine is securely packaged to ensure safe delivery. Each machine is wrapped in protective foam and enclosed in a sturdy wooden crate to prevent damage during transit. The packaging is designed to withstand rough handling and environmental factors, providing maximum protection for the equipment.

Shipping:

We offer worldwide shipping for the Transformer Coil Winding Machine. The product is shipped via reliable freight services with tracking available for every order. Delivery times may vary depending on the destination, and customers will be provided with estimated shipping dates at the time of purchase. Proper documentation and customs clearance support will be provided to facilitate smooth international shipping.

FAQ:

Q1: What is the minimum order quantity for the Transformer Coil Winding Machine?

A1: The minimum order quantity is 1 set.

Q2: What certifications does the Transformer Coil Winding Machine have?

A2: Our machine is certified with CE standards.

Q3: What is the delivery time for the machine?

A3: The delivery time is 30–35 days.

Q4: What are the payment terms available for purchasing the Transformer Coil Winding Machine?

A4: We accept T/T as payment methods.

Q5: How is the Transformer Coil Winding Machine packaged for shipping?

A5: The machine is packaged in an export wooden case to ensure safe delivery.
