Transformer Foil Winding Machine with 900mm Center Height, Cold Pressure Welding, and 11kW Winding Power for Industrial Energy Solutions

Center Height 900mm Transform Foil Wind Machine featuring Main Shaft Size 80x80x950mm Wind Power System for Industrial Energy Solutions

Product Description:

The Transformer Foil Winding Machine, commonly referred to as the TFF Winding Machine, is an advanced piece of equipment designed specifically for the precise and efficient winding of transformer foils. This machine is engineered to meet the demanding requirements of transformer manufacturing, ensuring high-quality output while maintaining operational efficiency. With its robust construction and innovative features, the TFF Winding Machine stands out as a reliable solution for both small-scale and large-scale production environments.

One of the key highlights of the Transformer Foil Winding Machine is its dual Insulation Decoiler system. Equipped with 2 Pcs insulation decoilers. This feature ensures that the insulation material is correctly aligned and tensioned, thereby preventing defects and ensuring consistent winding quality.

The TFW Machine utilizes an advanced Cold Pressure Welding mode to secure the foil layers during the winding process. Cold pressure welding is a critical feature that guarantees strong and reliable joints between the aluminum or copper foils, which are the primary winding materials used in transformer production. This welding technique not only improves the mechanical strength of the winding but also enhances electrical conductivity, which is vital for transformer efficiency and longevity. The incorporation of  cold pressure welding technology in the TFW Machine reflects its commitment to delivering superior product quality.

When it comes to winding materials, the Transform Foil Wind Machine offers versatility by accommodating both aluminum and copper foils. These materials are widely used in transformer manufacturing due to their excellent electrical properties. The ability to handle both types of foil allows manufacturers to cater to diverse transformer specifications and customer requirements. Whether the application demands the lightweight characteristics of aluminum or the superior conductivity of copper, this machine is fully equipped to manage the winding process effectively.

The winding power of this machine is rated at a robust 11kw, providing ample energy to drive the winding mechanism with precision and consistency. This power rating ensures that the machine operates smoothly under varying load conditions, maintaining steady speed and tension control throughout the winding cycle. The substantial power capacity also translates to higher winding speeds and improved overall throughput, making the TFF Winding Machine a valuable asset for boosting production efficiency.

Another important design specification of the Transformer Foil Winding Machine is its center height of the winding shaft, which stands at 900mm. This ergonomic height is optimized for ease of operation and maintenance, allowing operators to work comfortably and safely. The 900mm center height also facilitates better integration with other production line equipment, enabling streamlined workflows and reducing the need for additional adjustments or modifications.

In summary, the Transformer Foil Winding Machine (TFF Winding Machine) is a high-performance, versatile, and reliable solution tailored for the transformer manufacturing industry. Its dual insulation decoiler setup, cold pressure welding capability, compatibility with aluminum and copper foils, powerful 11kw winding motor, and ergonomic 900mm center height collectively contribute to its outstanding operational efficiency and product quality. Whether referred to as the TFW Machine or the Transform Foil Wind Machine, this equipment is designed to meet and exceed the exacting standards of modern transformer foil winding applications.

Features:

• Product Name: Transformer Foil Winding Machine
• Center Height: 900mm
• Decoiler Width: 61050mm
• Welder Type: Cold pressure welding
• High precision and efficiency in foil winding for transformers
• Durable construction ensuring long-term usage of the Transform Foil Wind Machine
• Advanced control system for consistent performance of the Transform Foil Wind Machine

Technical Parameters:

Applications:

The STT BRJ600-2 Transformer Foil Winding Machine is a highly efficient and versatile piece of equipment designed for a wide range of industrial applications. This advanced TFF Winding Machine is ideal for manufacturers specializing in the production of transformers and other electrical components that require precise and reliable foil winding. Its capability to handle aluminum or copper foil winding materials with a thickness ranging from 0.2 to 2.0mm makes it suitable for various transformer specifications, ensuring optimal performance and durability of the final product.

One of the primary application occasions for the Transformer Foil Wind Device is in transformer manufacturing plants where high-volume and high-precision foil winding are critical. The machine’s maximum foil width of 600mm and decoiler width of 650mm allow it to accommodate large-scale winding projects, making it perfect for both low and high voltage transformer production. Additionally, its center height of 900mm is ergonomically designed to facilitate easy operation and maintenance, thus reducing downtime and increasing productivity.

In scenarios where customization and flexibility are required, the STT BRJ600-2 Transform Foil Wind Machine excels due to its adaptable design and high supply ability of 100 sets per year. This makes it an excellent choice for businesses looking to scale their operations or diversify their product offerings. The machine is also well-suited for use in research and development centers focused on developing new transformer technologies, as its precise winding capabilities support experimentation with different foil materials and thicknesses.

Furthermore, the packaging details featuring Seaworth Packing ensure that the machine is securely protected during transportation, making it reliable for international shipping. With a delivery time of 45 days and negotiable pricing, it aligns well with project timelines and budget considerations. Payment terms via T/T provide additional convenience for global customers. The minimum order quantity of just one set allows small and medium enterprises to benefit from this sophisticated technology without the need for large upfront investments.

Overall, the STT BRJ600-2 Transformer Foil Winding Machine is an essential tool for any operation involved in foil winding processes. Whether it is used as a core piece of equipment in a transformer manufacturing line or a specialized device in a technical lab, this TFF Winding Machine offers precision, reliability, and efficiency. Its robust construction and advanced features make it a valuable asset in scenarios demanding high-quality foil winding, ultimately contributing to the production of superior electrical transformers.

Customization:

STT proudly presents the Transformer Foil Winding Machine, model number BRJ600-2, designed to meet your precision winding needs. This TFW Machine supports a minimum order quantity of 1 set, with prices negotiable to suit your budget.

Equipped with two decoiler pieces, the Transformer Foil Winding Machine can handle copper foil widths ranging from 200mm to 600mm. Its advanced cold pressure welding mode ensures efficient and reliable operation.

Each unit is carefully packed using seaworth packing to guarantee safe delivery. The standard delivery time is 45 days, with payment terms based on T/T. STT offers a supply ability of 100 sets per year, ensuring consistent availability of the TFW Machine.

Choose the STT Transformer Foil Winding Machine for superior quality and customizable options tailored to your production requirements.

Support and Services:

Our Transformer Foil Winding Machine comes with comprehensive technical support and services to ensure optimal performance and longevity. We provide detailed user manuals and setup guides to facilitate easy installation and operation. Our expert technical team is available to assist with troubleshooting, maintenance advice, and machine calibration to meet your specific winding requirements.

We offer preventive maintenance services and on-site inspections are available to minimize downtime and extend the lifespan of your equipment. Training sessions are provided for your operators to maximize productivity and ensure safe handling of the Transformer Foil Winding Machine. Additionally, we supply genuine spare parts and accessories to maintain machine integrity and performance. Our commitment is to deliver prompt and reliable support, ensuring your Transformer Foil Winding Machine operates efficiently, helping you achieve precise and high-quality transformer foil winding results.

Packing and Shipping:

Product Packaging:  The Transformer Foil Winding Machine is securely packed using high-quality materials to ensure maximum protection during transit. The machine is wrapped in protective plastic film to prevent dust, moisture, and mechanical damage. It is then placed into a container.

Shipping:  The Transformer Foil Winding Machine is shipped via reliable freight carriers to ensure timely and safe delivery. Depending on the destination and customer preference, shipping options include sea freight, or land transportation. The shipment is fully insured to protect against loss or damage during transit. Tracking information is provided to the customer for real-time updates. Upon arrival, the machine should be inspected for any possible damage before acceptance.

FAQ:

Q1: What is the brand and model number of the Transformer Foil Winding Machine?

A1: The Transformer Foil Winding Machine is from the brand STT, and the model number is BRJ600-2.

Q2: What is the minimum order quantity for this machine?

A2: The minimum order quantity for the Transformer Foil Winding Machine is 1 set.

Q3: What are the payment terms available for purchasing this machine?

A3: The payment terms for the Transformer Foil Winding Machine are T/T (Telegraphic Transfer).

Q4: How long is the delivery time after placing an order?

A4: The delivery time for the Transformer Foil Winding Machine is approximately 45 days.

Q5: How is the Transformer Foil Winding Machine packaged for shipment?

A5: The machine is packaged using seaworth packing to ensure safe delivery.

Q6: What is the supply capacity of the Transformer Foil Winding Machine?

A6: The supply ability is 100 sets per year.

Q7: Is the price fixed or negotiable?

A7: The price of the Transformer Foil Winding Machine is negotiable.
