Automatic Transformer Coil Winding Machine with 500mm Max Winding Width and 0.75KW Servo Motor Featuring 4-Jaw Chuck Head Stock

Automatic Transformer Coil Winding Machine Equipped with Servo Motor 075KW Max Winding Width 500mm Ensuring Consistent Coil

Product Description:

The Transformer Coil Winding Machine ZPX500 is a piece of equipment designed to wind wire  coils. Specifically engineered for precision and efficiency, this winding machine is ideal for producing high-quality coils used in transformers and various electrical devices. Featuring a robust design and advanced functionality, the Transformer Coil Winding Machine ensures consistent winding accuracy, making it an indispensable tool in both small-scale workshops and large industrial settings.

One of the standout features of this Transformer Coil Winding Machine is its 4-jaw Chuck head stock. This component ensures that the wire spool is held securely in place during the winding process, minimizing slippage and enhancing stability. The 4-jaw Chuck allows for quick and easy adjustment, accommodating different spool sizes and providing greater versatility. This feature significantly contributes to the machine’s ability to handle various coil dimensions without compromising precision.

The machine supports a maximum coil height of up to 500 millimeters per coil, making it suitable for a broad range of transformer coil sizes. This capability allows manufacturers to produce coils with different dimensions, catering to diverse applications in the electrical industry.

Material versatility is another key advantage of this CNC Coil Winding Machine. It is compatible with both copper and aluminium wire, which are the two primary materials used in transformer coils. Copper wire is prized for its excellent electrical conductivity and durability, while aluminium wire offers a lightweight, cost-effective alternative. The ability to work with either material allows manufacturers to optimize their production based on budget, performance requirements, and availability of raw materials.

As a CNC Coil Winding Machine, this transformer coil winder incorporates computerized numerical control technology, which automates the winding process with high accuracy. This automation allows for programmable winding patterns, adjustable tension control, and repeatable precision. Operators can easily configure the machine to produce complex coil geometries, reducing manual labor and increasing production efficiency. This level of control is essential for manufacturing high-quality transformer coils that meet industry standards.

In addition to its technical specifications, the Transformer Coil Winding Machine is built with durability and ease of maintenance in mind. The robust construction and high-quality components ensure long service life and reliable performance under continuous operation. Maintenance procedures are straightforward, minimizing downtime and allowing manufacturers to maintain high throughput. This reliability makes it an excellent investment for companies looking to enhance their coil production capabilities.

Whether used for small batch production or large-scale manufacturing, this Transformer Coil Winding Machine delivers exceptional performance and versatility. Its combination of a 4-jaw Chuck head stock, a maximum coil height of 500mm, compatibility with copper and aluminium wire, and so on makes it a comprehensive solution for all transformer coil winding needs. Furthermore, its CNC capabilities enable precise control and consistency, essential for producing high-quality toroidal and other specialized coils.

In summary, the Transformer Coil Winder represents the ideal fusion of advanced technology and practical design. It is a reliable, efficient, and versatile Coil Winding Machine capable of meeting the rigorous demands of the electrical manufacturing industry. By investing in this CNC Coil Winding Machine, manufacturers can achieve superior coil quality, increased productivity, and greater flexibility in their production processes.

Features:

• Product Name: Transformer Coil Winding Machine
• Type: ZPX500
• Operation: Automatic Coil Winding Machine
• Maximum Flat Wire Size: 5x12mm
• Maximum Winding Width: 500mm
• Head Stock: 4-jaw Chuck
• Round Wire Diameter Range: Ø0.3 - 5.0mm
• Application: Transformer Winding Machine

Technical Parameters:

Applications:

The Transformer Coil Winding Machine, offered under OEM or Custom Brand from China, is a highly versatile and efficient piece of equipment designed specifically for winding transformer coils with precision and consistency. Certified with CE, this machine guarantees high quality and reliability, making it an ideal choice for various industrial applications. Its robust construction supports winding materials such as copper or aluminium wire, catering to different transformer coil manufacturing requirements.

This Automatic Coil Winding Machine is widely used in electrical equipment manufacturing plants, where precision and speed are critical. It is perfect for producing coils for transformers and other electromagnetic devices. The machine’s maximum winding width of 500mm. The machine’s 4kw power ensures stable operation, even under continuous production cycles.

With a minimum order quantity of just 1 set, the Transformer Coil Winding Machine is accessible to both small workshops and large manufacturing facilities. Its competitive price range of USD 8,000 to 15,000 per set, paired with flexible payment terms including T/T, facilitates easy procurement. The machine is delivered in export wooden cases to ensure safe shipping, with delivery times ranging from 35-40 days.

Manufacturers can reliably count on consistent availability to meet production demands. This Automatic Coil Winding Machine is perfectly suited for various application occasions such as coil winding workshops, transformer manufacturing lines, and research and development labs focused on electromagnetic components. Whether producing standard transformer coils or other similar coils, this machine enhances productivity, reduces labor intensity, and improves winding accuracy, making it an indispensable tool in modern coil manufacturing.

Customization:

Our Transformer Coil Winding Machine offers comprehensive product customization services tailored to meet your specific requirements. As a trusted manufacturer based in China, we provide OEM and Custom Brand options to ensure your Electrical Coil Winding Equipment perfectly aligns with your brand identity.

The machine is certified with CE certificate, guaranteeing the highest quality and safety standards. With a minimum order quantity of just 1 set, we accommodate both small and large scale needs. Pricing ranges from USD 8,000 to 15,000 per set, depending on the configuration and customization level. Each unit is carefully packaged using export wooden cases to ensure safe delivery. We offer seaworthy packing to protect the equipment during international shipping.

Our payment terms are flexible, accepting T/T, to facilitate smooth transactions. With a supply ability of 100 sets per year, we are well-equipped to fulfill your orders promptly. The Transformer Coil Winding Machine features a powerful 0.75KW servo motor and a sophisticated PLC control system for precise and efficient operation. It supports round wire diameters ranging from Ø0.3 to 5.0mm, suitable for various coil winding applications.

Support and Services:

Our Transformer Coil Winding Machine is designed to provide precise and efficient winding solutions for transformer manufacturing. We offer comprehensive technical support and services to ensure optimal performance and longevity of your equipment.

Technical Support: Our experienced technical team is available to assist you with installation, setup, and troubleshooting of the Transformer Coil Winding Machine. We provide detailed user manuals, operation guides, and maintenance instructions to help you maximize the machine's capabilities.

Training Services: If needing, we also offer training sessions for your operators and maintenance personnel to ensure proper handling and upkeep of the winding machine. This training covers machine operation, and routine maintenance procedures.

Maintenance and Repair: Regular maintenance services are available to keep your Transformer Coil Winding Machine running smoothly. Our technicians can perform inspections, calibration, and repairs as needed, minimizing downtime and extending the machine’s service life.

Spare Parts: We supply genuine spare parts and accessories compatible with your Transformer Coil Winding Machine.

Customer Support: Our customer support team is committed to providing timely assistance and resolving any technical issues you may encounter. We strive to ensure your complete satisfaction with our products and services.

Packing and Shipping:

Product Packaging and Shipping

The Transformer Coil Winding Machine is carefully packaged to ensure safe delivery and optimal protection during transportation. Each machine is securely wrapped with protective materials such as stretch film to prevent any damage from shocks or vibrations.

For shipping, we offer multiple options including sea freight. The packaging is designed to comply with international shipping standards, ensuring the product reaches the customer in perfect condition. Detailed shipping documentation, including user manuals and warranty cards, is included inside the package. Our logistics team coordinates with reliable carriers to provide timely and secure delivery, and tracking information is provided to customers for real-time updates on their shipment status.

FAQ:

Q1: What is the brand name of the Transformer Coil Winding Machine?

A1: The machine is available under OEM or custom brand names according to your requirements.

Q2: Where is the Transformer Coil Winding Machine manufactured?

A2: Our Transformer Coil Winding Machines are manufactured in China.

Q3: What certifications does this machine have?

A3: The machine is certified with CE standard, ensuring quality and safety.

Q4: What is the minimum order quantity and price range?

A4: The minimum order quantity is 1 set. The price ranges from USD 8,000 to 15,000 per set depending on the model and specifications.

Q5: What are the delivery times and payment terms?

A5: Delivery time is 35-40days. Payment can be made via T/T.

Q6: How is the Transformer Coil Winding Machine packaged for shipment?

A6: The machine is packaged in export wooden cases or vacuum packaging to ensure safe delivery.

Q7: What is the yearly supply capacity for this machine?

A7: We can supply up to 100 sets of Transformer Coil Winding Machines per year.
