Three Heads CNC Winder | ZPX150-3 Automatic Coil Winding Machine

Product Description

The ZPX150-3 three-head coil winding machine is a high-efficiency industrial winder for transformer and electromagnetic coil production. Equipped with three servo-driven wire guides, it can wind three coils simultaneously to greatly boost output. Adopting PLC and HMI touchscreen control, the coil winding machine supports simple parameter setup and intuitive operation. The coil winding machine features soft start, stable running performance and high automation, ideal for mass production of copper and aluminum wire coils. Custom build is available to match unique production requirements.

Main Components

• Heavy-duty welded steel main frame
• Main winding unit: includes winding motor and winding shaft
• Automatic wire laying unit driven by 750W servo motor
• PLC control system
• Pneumatic system
• Servo motors
• Foot pedal for convenient operation

Technical Parameters

Standard specifications for ZPX150-3 three-head coil winding machine are listed below. Customization is available upon request.

Fig 1: Automatic coil winding machine ZPX150-3's full view

Fig 2: Automatic coil winding machine ZPX150-3's wire guide
