Automatic Corrugated Fin Forming Machine Making Transformer Tank Shell

Automatic Corrugated Fin Forming Machine Making Transformer Tank Shell

Automatic Corrugated Fin Forming Machine Making Transformer Tank Shell
Automatic Corrugated Fin Forming Machine Making Transformer Tank Shell

Large Image :  Automatic Corrugated Fin Forming Machine Making Transformer Tank Shell Get Best Price

Product Details:
Place of Origin: China
Brand Name: STT
Certification: CE
Model Number: BWX1600-400
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: seaworthy packing
Delivery Time: 60 days
Payment Terms: T/T, L/C
Supply Ability: 100 sets per year
Detailed Product Description
Name: Corrugated Fin Making Machine Plate Width: 300 ~ 1600mm
Fin Height: 50 ~ 400mm Fin Pitch: 45 ~ 60mm
Fin Length: ≤2000mm Machine Color: Optional
Oil Groove: 4mm Welding Machine: 2 Sets
High Light:

Auto Corrugated Fin Forming Machine

,

Corrugated Fin Forming Machine Automatic

,

Transformer Tank Shell Forming Machine

Automatic Corrugated Fin Forming Machine Making Transformer Tank Shell





Description of corrugated fin forming machine BWX1600-400



Automatic corrugated fin forming machine BWX1600-400 is a special equipment for making corrugated fins. This kind of corrugated fins server as transformer oil tank shell after being welded together. The full set of corrugated fin forming machine includes corrugated fin folding machine, automatic corrugated fin welding machine, hydraulic decoiler and industrial oil cooler. The corrugated fin forming machine features high automation, easy operation and so on.





Main components of corrugated fin forming machine BWX1600-400



1. Corrugated fin forming machine

2. Welding machine

3. Decoiler

4. Oil cooler





Quick details of corrugated fin forming machine BWX1600-400

  • Corrugated fin forming machine
  • Steel plate width 300 ~ 1600mm
  • Steel plate thickness 0.5 ~ 1.75mm
  • One year warranty



Main parameters of corrugated fin forming machine BWX1600-400



Typical standard specifications of corrugated fin forming machine BWX1600-400 are shown below, however, the fin forming machine can also be manufactured as requested.



Steel Plate Width: 300 ~ 1600mm
Steel Plate Thickness: 0.5 ~ 1.75mm
Corrugated Fin Height: 50 ~ 400mm
Corrugated Fin Pitch: 45 ~ 60mm
Corrugated Fin Length 2000mm, maximum
Fin Gap(oil groove): 4mm
Corrugated Fin Front Section Length: ≥30mm
Corrugated Fin Back Section Length: ≥30mm
Molding speed: 3 ~ 4 fins/min
Total Weight: 16000KG
Floor Space: 9m x 7m
Total Motor Power: 32kw



Automatic Corrugated Fin Forming Machine Making Transformer Tank Shell 0

Fig 1: Corrugated fin forming machine BWX1600-400's forming unit



Automatic Corrugated Fin Forming Machine Making Transformer Tank Shell 1

Fig 2: Corrugated fin forming machine BWX1600-400's welding machine



Automatic Corrugated Fin Forming Machine Making Transformer Tank Shell 2Automatic Corrugated Fin Forming Machine Making Transformer Tank Shell 3Automatic Corrugated Fin Forming Machine Making Transformer Tank Shell 4

Automatic Corrugated Fin Forming Machine Making Transformer Tank Shell 5Automatic Corrugated Fin Forming Machine Making Transformer Tank Shell 6
