Product Details:
Payment & Shipping Terms:
|
| Product Name: | Foil Winding Machine | Function: | Winding Transformer Coil |
|---|---|---|---|
| Power: | 22kw | Rotating Speed: | 0 ~ 18 Rpm |
| Cu Film Thickness: | 0.2 ~ 2.0mm | Al Film Thickness: | 0.3 ~ 3.0mm |
| Deburring Unit: | 2 Sets | Warranty: | 12 Months |
| Highlight: | Programmable Transformer Winder,Dry Type Transformer Foil Winding Machine,Transformer Winder With PLC Control |
||
Electronic Programmable Dry Type Transformer Foil Winding Machine With PLC Control
Description of transformer foil winding machine BRJ1400-2
Transformer foil winding machine BRJ1400-2 is a special winder for winding transformer coil. The transformer foil winding machine is widely used to wind copper foil or aluminium foil, which can make dry type transformer foil coils and other similar products. The transformer foil winding machine can wind two layers of foil and two layers of insulation paper. The transformer foil winding machine is composed of winding unit, welding unit, cleaning unit, deburring unit, feeding unit and so on. With TIG welding unit, the transformer foil winding machine can weld foil and bus bar together automatically. The transformer foil winding machine is control by PLC.
Main components of transformer foil winding machine BRJ1400-2
1. Main frame
2. Winding unit
3. Foil decoiler
4. Insulation decoiler
5. End-filling strip feeder
6. Cleaning system
7. Cutting system
8. Foil deburring system
9. Edge alignment system
10. Automatic welding unit
11. Electronic control system
12. Pneumatic system
Technical parameters of transformer foil winding machine BRJ1400-2
Typical standard specifications of transformer foil winding machine BRJ1400-2 are shown below, however, the transformer foil winding machine can also be manufactured as requested.
| Maximum Foil Width: | 1,400mm |
| Max. Finished Coil OD.: | 1,000mm |
| Finished Coil Shape: | oval, round and rectangular,etc. |
| Conductor Foil Material: | Copper or Aluminum |
| Maximum Conductor Material OD.: | Φ1,000mm |
| Conductor Material ID.: | Φ500mm |
| Foil Decoiler Number: | 2 pcs |
| Foil Decoiler Expanding Range: | Φ460 ~ 520mm |
| Max. Coil Weight: | 2,500KG |
| Winding Mandrel Size: | 80×80×1750 mm |
| Welding Mode: | TIG |
| Cutting Mode: | Electric disc shear |
| Insulation Decoiler Number: | 2 pcs |
| Max. Insulation Material OD.: | Φ400mm |
| Insulation Material ID.: | Φ76mm |
| End-filling Strip Feeder: | 8 pcs |
| Edge Alignment System: | Photoelectric sensing |
| Control System: | PLC |
| User Interface: | 10inch (254mm) touch screen |
| Counting Range: | 0 - 9999.9 |
| Total Weight: | 8000Kg |
| Dimension(LxWxH) | 5800x2850x2500mm |
Fig 1: Transformer foil winding machine BRJ1400-2's front view
Fig 2: Transformer foil winding machine BRJ1400-2's back view
