Product Details:
Place of Origin: China
Brand Name: STT
Certification: CE
Model Number: ZPT-3T
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: seaworthy packing
Delivery Time: 35 days
Payment Terms: T/T, L/C
Supply Ability: 100 sets per year
Detailed Product Description
Product Name: Transformer Core Stacking Table Usage: Assembly Armorphous Transformer Iron Core
Max. Capacity: 3000kg Max. Stoke: 300mm
Power: 2.2kw Color: Optional
Tilting: Hydraulic Warranty: 12 Months
High Light:

Amorphous Hydraulic Transformer Core Stacking Table

,

Adjustable Lap Transformer Core Stacking Table

Amorphous Transformer Core Stacking Table Adjustable Lap Core Stacking Table





Description of transformer core stacking table ZPT-3T



Transformer core stacking table ZPT-3T is a professional transformer making equipment, which is mainly used to stack transformer iron cores. This stacked cores can be used to pruduce amorphous transformers and other similar products. The transformer core stacking table can be adjustable to assembly different sizes of core. The core stacking table is designed to facilitate the precise and efficient stacking of amorphous transformer cores, which are crucial components for electrical power transformers and the transformer core stacking table ZPT-3T’s maximum capacity is 3000kg. Moreover, the transformer core stacking table can tilt the stacked core, which makes the stacked core be taken away from the table easily. The transformer core stacking table features easy operation, smooth running and so on.





Quick details of transformer core stacking table ZPT-3T



  • Platform height 850mm
  • Hydraulic station
  • Linear guide
  • Maximum capacity 3000kg
  • Motor power 2.2kw
  • Hydraulic pressure 21MPa



Main Parameters of transformer core stacking table



Typical standard specifications of transformer core stacking table ZPT-3T are shown below, however, the stacking table can also be manufactured as requested.

No. Item ZPT-3T
1 Working height: 850mm
2 Applicable Product Size:

L:700-1600mm

W:360-700mm

H:400-900

3 Lifting Platform Loading Capacity: 3000Kg
4 Lifting Platform Stroke: 300mm
5 Lifting Speed: 40mm/s
6 Total Power: 2.2Kw
8 Stacking Table Weight 1500Kg
8 Applicable Transformer capacity 30KVA-2000KVA
9 Rotating Angle 90°
10 Hydraulic Working Pressure 21MPa


Amorphous Transformer Core Stacking Table Adjustable Lap Core Stacking Table 0
Fig 1: Transformer core stacking table ZPT-3T's full view

Amorphous Transformer Core Stacking Table Adjustable Lap Core Stacking Table 1
Fig 2: Transformer core stacking table ZPT-3T's tilting

Amorphous Transformer Core Stacking Table Adjustable Lap Core Stacking Table 2Amorphous Transformer Core Stacking Table Adjustable Lap Core Stacking Table 3Amorphous Transformer Core Stacking Table Adjustable Lap Core Stacking Table 4Amorphous Transformer Core Stacking Table Adjustable Lap Core Stacking Table 5Amorphous Transformer Core Stacking Table Adjustable Lap Core Stacking Table 6Amorphous Transformer Core Stacking Table Adjustable Lap Core Stacking Table 7Amorphous Transformer Core Stacking Table Adjustable Lap Core Stacking Table 8
